This study was published in the November/December issue of The International Journal of Oral and Maxillofacial Implants (JOMI), the official journal of the Academy of Osseointegration (AO).
"This article evaluated a number of implant/abutment combinations, from several major implant manufacturers as well as several ‘value’ brands, testing for the amount of micromotion between components in an in vitro model. Of significance in the clinical setting is, it's important to be aware of the wide range of micromotion noted, which may impact an implant's long-term success. There also was a significant effect of the amount of torque used for screw tightening, which suggests the possible utility of retightening of the abutment screws after a period of initial loading.” — Alan Pollack, DDS, Academy of Osseointegration board member
Background: Micromotion at the implant-abutment level has been identified as a major determinant of long-term implant success. Technical problems ranging from screw loosening to screw fracture may occur as a consequence of excessive micromotion. Different concepts for the design of the implant-abutment connection have been proposed in the past, which affect micromotion at the restorative interface as well as the stability of the abutments used. While initial micromotion depends predominantly on the fabrication accuracy achieved, long-term micromotion appears to be related primarily to wear phenomena at the implant-abutment interface. Despite the clinical importance of micromotion phenomena at the implant-abutment interface, no universally valid method for quantifying this phenomenon has been described.
Key point: It cannot be predicted that a certain type of abutment will always lead to a certain level of micromotion. Relative displacement of components occurs at varying magnitudes. However, strict adherence to manufacturers’ guidelines with respect to tightening torque may help reduce implant-abutment micromotion. Because micromovement occurs during the initial phase of loading, it may be prudent to routinely retighten the abutment screws, which might have lost preload.
Authors: Dr. Matthias Karl, Department of Prosthodontics, University of Erlangen-Nuremberg, Erlangen, Germany; Dr. Thomas D. Taylor, Department of Reconstructive Sciences, University of Connecticut, Farmington, Connecticut.
Purpose: Scientists aimed to establish a biomechanical approach to directly measure relative motion at the implant-abutment interface and to quantify micromotion in a variety of implant-abutment combinations. Geometry of the implant-abutment interface, fabrication method of the abutment, engagement of antirotational features, abutment material, tightening torque, and type of manufacturer (original, clone) were investigated.
Materials and methods: Implant-abutment assemblies were fixed in a universal testing machine at a 30-degree angle. A cyclic load of 200 N (Newtons) was applied to the specimens 10 times at a cross-head speed of 100N/s, while relative displacement between the implant and the abutment was quantified using extensometers. For five consecutive loading cycles per specimen, micromotion was recorded as a basis for statistical analysis. Comparative analysis was based on Welch tests.
Figure 2:Screenshot from the analysis software showing the correlation of implant and abutment displacement with loading force. A total of 10 loading cycles were performed for each implant-abutment combination, and five datasets per combination formed the basis for statistical analysis. Note: Because of the experimental setup, movements of the abutment bear a negative sign.
Results: Investigated implant-abutment combinations produced a broad range of micromotion values. Researchers did not find perfect implant shoulder geometry or a perfect fabrication technique that would result in undetectable micromotion. The values for micromotion at the implant-abutment interface ranged from 1.52 µm to 94.00 µm (micrometers). Researchers found tightening torque significantly affected the level of micromotion when one specific abutment type was investigated. Implant shoulder design did not reveal a significant effect in all cases. Lack of engagement of antirotational features of the implants resulted in increased micromotion, regardless of the implant system investigated. Casting onto prefabricated gold cylinders resulted in abutments with significantly less micromotion compared to copy-milled stock abutments. Computer-aided design/computer-assisted manufacture (CAD/CAM) zirconia abutments showed less micromotion than CAD/CAM titanium abutments. Inconsistent levels of micromotion were recorded for CAD/CAM abutments coupled to proprietary and competing implant systems. In most cases, the CAD/CAM abutments performed as well as stock abutments. Great variations in micromotion were found with clone abutments and clone implant systems (Figures 1 and 2).
More information: For a complete copy of the study and the JOMI November/December Table of Contents, visit http://www.osseo.org/NEWIJOMI.html. To join AO and begin receiving JOMI (bimonthly) or obtain online access to JOMI, visit http://www.osseo.org/NEWmembershipApply.html.
